Tesira SERVER
Configurable I/O DSP with 1 DSP-2 card (7 additional DSP-2 cards can be added) and 1 AVB-1 network card.
Configurable I/O DSP with 1 DSP-2 card (7 additional DSP-2 cards can be added) and 1 AVB-1 network card.
Key Features
- Supports up to 8 DSP-2 cards
- Up to 420×420 channels of digital I/O over AVB
- Supports optional 32×32 CobraNet audio networking
- Supports optional 64×64 Dante audio networking
- System configuration and control via Ethernet or serial connection
- Front panel OLED display for device and system information
- SpeechSense processing algorithm
- Signal processing via intuitive software allows configuration and control for signal routing and mixing, equalization, filtering, dynamics, delay and much more
- Extensive input, output and logic expansion devices supported as part of the Tesira digital audio networking platform
- Supports media network redundancy for continuous uptime
- Supports port authentication via IEEE 802.1X
- Rack mountable (3RU)
- CE marked, UL listed, and RoHS compliant
- 5-year warranty
- Compliant with the US Trade Agreement Act (TAA)
Tesira® SERVER is a configurable I/O digital signal processor for use with the Tesira digital audio networking platform. It is factory configured with one DSP card and capable of handling up to seven additional DSP cards. It is also factory configured with one AVB-1 Audio Video Bridging digital audio networking card. A second card slot can be populated with an additional AVB card, an SCM-1 CobraNet® network card, or a DAN-1 Dante⢠network card. In cases where local I/O is advantageous, a Tesira standard I/O card may be installed. The configurable I/O DSP features Biamp SpeechSense⢠technology, which enhances speech processing by more accurately distinguishing between human speech and noise. The DSP also provides extensive audio processing, including but not limited to: signal routing and mixing, equalization, filtering, dynamics, and delay as well as control, monitoring and diagnostic tools; all configured through the Tesira software. The SERVER supports primary and secondary redundant media network connections to provide resilient audio streaming. If the primary media network experiences downtime, the secondary connection takes over with no loss of continuity.
The SERVER is the core of a Tesira digital audio system and can be used with Tesira expanders to form a highly scalable audio network. Tesira SERVER supports primary and secondary redundant media network connections to provide resilient audio streaming. If the primary media network experiences downtime, the secondary connection takes over with no loss of continuity.
The Tesira SERVER complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractorsâ sales bids for the U.S. federal government.
