Commercial Audio D-ALINP
Local input wall control panel for connecting a music source and/or dynamic microphone.
Local input wall control panel for connecting a music source and/or dynamic microphone.
Key Features
- Input wall control panel
- Connect music source and/or dynamic microphone
- 5-year warranty
In lots of applications a local input control can be a useful and above all a timesaving product. No complex devices with multiple buttons to control — just plug in and control the volume, nothing more, nothing less!
Especially in rooms where very often a music source or microphone is used, the D-ALINP plays its role. Think of classrooms where each hour a different teacher uses the classroom and wants to plug in his laptop or meeting rooms where presentations are given on a regular basis. What about multi-function rooms, bars, restaurants or banquet rooms? With the D-ALINP you can easily connect your device.
The D-ALINP is a local input wall control panel that makes it possible to connect a music source and/or dynamic microphone. The connected music source (via stereo line-in summed to mono internally) and microphone (via XLR-input) have insectionidual volume control.
The built-in mic pre-amplifier and high-quality input transformer (to avoid ground loops) guarantees an exceptional audio quality. The line and microphone input are automatically mixed together so that only one input at your pre-amplifier or mixing amplifier is used. The XLR microphone input is not providing phantom power.
As the D-ALINP functions with a 24 to 48V phantom power supply it is extremely versatile and can be used with any mixing desk, matrix or pre-amplifier that has a MIC/Line input with at least 24V phantom power supply (e.g. AUDIOCONTROL12.8, PM1122 (with modification), MA247 (MR), MA30/60/120/240, ZONE4 (with modification), PREZONE … ).
The D-ALINP fits into any standard Decora in-wall box.
