Community IP8-1122/26B
High power, 12-inch, 2-way, 120 X 60 loudspeaker, black.
High power, 12-inch, 2-way, 120 X 60 loudspeaker, black.
Key Features
- 120° H x 60° V dispersion
- Indoor installation, black finish
- High-flux, linear neodymium motors with demodulation rings for very low distortion
- Exceptional sound quality and clarity at very high output levels
- Lightweight and compact with deep LF extension
- Large rotatable waveguide with insectionidually voiced crossover, single-amp/bi-amp selectable
- Innovative low profile modular bracket systems create elegant arrays with simplified installation
- 5-year warranty
- Compliant with the US Trade Agreement Act (TAA)
The IP8-1122 is a high power, 12-inch, two-way, point source loudspeaker. The rotatable 13-inch (330mm) HF waveguide provides well-defined coverage and a smooth off-axis response that enhances arrayability. Insectionidually voiced crossovers produce proper beamwidth matching transitions and identical sonic signatures, permitting horn patterns to be mixed throughout an installation. Additionally, user selectable single amp or biamp operating modes expand application flexibility. FEA-optimized linear suspensions, high-flux neodymium motors, and integral demodulation rings ensure precise control and very low distortion at high SPL levels. The custom long-excursion LF driver delivers deep bass response and a balanced midrange in the most demanding applications. The HF compression driver’s non-metallic diaphragm provides natural, transparent sound quality that accurately reproduces and complements any source. I SERIES Point Source 800 loudspeakers provide exemplary acoustic performance, modular flexibility and elegant aesthetics for modern performance venues. Designed to support the goals of systems integrators and consultants both acoustically and mechanically, I SERIES includes a wide variety of arrayable, rotatable coverage patterns and a comprehensive selection of modular bracket systems that accelerate system design and system commissioning.
AMPLIFIED LOUDSPEAKER CONTROLLERS
Community ALC1604D New Window is recommended for this product. Higher power ALC models may be used safely as well.
The IP6-1152 complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractorsâ sales bids for the U.S. federal government.
