Biamp Tesira EX-AEC 4-channel mic/line input expander with AEC and PoE+

Login to see prices

Key Features

Four channels of balanced microphone or line level input with AEC (Acoustic Echo Cancellation)
0 – 66 dB gain, adjustable in 6 dB increments
+48 volts Phantom Power
-100 to +12 dB fader range for level
Audio and control networking over AVB/TSN
Powered by PoE+
Plug-in barrier strip connectors
Front panel LEDs for device status indications
Half-rack chassis
RoHS compliant and AES grounded
5-year warranty
Compliant with the US Trade Agreement Act (TAA)

Get a Quote

Add to compare

Add to wishlist

Shipping & Delivery

Courier delivery

Our courier will deliver to the specified address

2-3 Days

From $20

DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From $40

Warranty 1 year

More details

Free 30-Day returns

More details

Specification

Overview

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Processor

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Display

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

RAM

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Storage

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Video Card

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Connectivity

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Features

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Battery

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

General

TAA Compliant	TAA Compliant
Humidity	0-95% relative humidity (non-condensing)
Audio	4 channels of analog audio, the EX-AEC is a 4-channel mic/line level input expander with AEC (acoustic echo cancellation)
Height	1.75 inches (44 mm)
Weight	3 lbs (1.4 kg)
Ambient Operating Temperature Range	32 – 104° F (0 – 40° C)
Altitude	0-10,000 ft (0-3000m) MSL
Certifications	FCC Part 15B (USA) CE marked (Europe) UL and C-UL listed (USA & Canada) RCM (Australia) EAC (Eurasian Customs Union) RoHS Directive (Europe)
Power	PoE+ (IEEE 802.3at Class 4 , 30W)
Width	8.5 inches (216 mm)
Depth	7.75 inches (197 mm)

Description

Tesira EX-AEC

4-channel mic/line input expander with AEC and PoE+.

Key Features

Four channels of balanced microphone or line level input with AEC (Acoustic Echo Cancellation)
0 – 66 dB gain, adjustable in 6 dB increments
+48 volts Phantom Power
-100 to +12 dB fader range for level
Audio and control networking over AVB/TSN
Powered by PoE+
Plug-in barrier strip connectors
Front panel LEDs for device status indications
Half-rack chassis
RoHS compliant and AES grounded
5-year warranty
Compliant with the US Trade Agreement Act (TAA)

Get a Quote

The Tesira EX-AEC is a half-rack expander box for use with AVB-enabled Tesira server-class devices. The EX-AEC is a 4-channel mic or line level audio input expander with AEC (Acoustic Echo Cancellation). The expander communicates with the Tesira AVB network for audio networking, configuration, and control, and is powered by PoE+.

The Tesira EX-AEC complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractorsâ sales bids for the U.S. federal government.
