Vocia VI-8
Input device with 8 analog mic/line inputs, allows live audio paging within the Vocia platform.
Input device with 8 analog mic/line inputs, allows live audio paging within the Vocia platform.
Key Features
- Eight analog microphone/line level or CobraNet inputs
- One logic and four relay control outputs
- Eight logic inputs
- Device status monitoring via control logic input and output
- Power via dual 24 volt DC inputs (redundant inputs) power supply included
- Software-configurable signal processing including volume control, filters, and compressor/limiting
- Rack mountable (1RU)
- Dual CobraNet ports for redundant Ethernet connections
- Device and logic I/O status monitoring
- Rotary switches for device identification
- IP30 compliant
- CE marked and RoHS compliant
- 5-year warranty
- Compliant with the US Trade Agreement Act (TAA)
The Vocia Input 8 (VI-8) is designed to facilitate live audio paging from user sources to emergency and non-emergency zones in a Vocia system. The VI-8 will allow direct paging access from eight sources via analog mic/line level inputs or CobraNet digital audio connections. Nine logic inputs can be assigned to various Vocia control events including paging control. A logic output and four relay outputs can be assigned to control events. The logic output may be used to report status from one or several daisy-chained VI-8s to an external system. The logic inputs and output are monitored.
The Vocia Input 8 (VI-8) complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractorsâ sales bids for the U.S. federal government.
